Panasonic, a worldwide leader in Flash Memory Products, is pleased to introduce the NEW UE Series Consumer Plus SD Flash Memory Cards
for high capacity storage applications. The UE Series adopts MLC (Multi Level Cell) NAND flash memory which is more reliable than TLC (Triple
Level Cell) NAND flash memory. An extended operating temperature range of -25°C to +85°C allows use in severe conditions and the integrated
Panasonic Controller ensures long lifetime usage and high system performance. Quality is maintained with 100% product screening before
shipment to achieve low failure rate. Storage capacity options include 64GB and 128GB models.
New Product Introduction
NEW UE Series SD Flash Memory Cards
Consumer Plus MLC (Multi Level Cell) NAND Models For High Capacity Storage Applications
Features
• MLC (Multi Level Cell) NAND Flash Memory
• Enhanced Controller
• UHS-I Speed Grade #
• 100% Product Screening Test
• Available in 64GB and 128GB High Capacity Models
• RoHS/REACH Compliant
Part Number Information
Industries
• Automotive
• Avionics
• Measurement
For detailed specification information on the NEW UE Series Consumer Plus SD Flash Memory Cards, visit our website at:
na.industrial.panasonic.com/products/semiconductors/sd-cards
Applications
• Navigation
• Drive Recorders
• In Flight Entertainment Systems
• Flight Recorders
• Broadcast, Security and Professional Cameras
• Smart Meters (Energy/Gas)
• Handheld Terminals
Benefits
• Affordable and Reliable Data Storage Solution
• Extended Temperature Range of -25°C to +85°C for
Use in Severe Environments
• Higher Endurance and Data Retention Than TLC NAND
• Avoids Intensive Write With Wear Leveling Function
• SD Speed Class 10
• Low Failure Rate In Industrial Applications
SD I/F CapacityType
U=UE D=
MOQ:100
A=USA 1=Toshiba
19nm
64=64GB
12=128GB
E=
Consumer
Plus
Series Grade Disty USA NAND
Process
RP SD 64U E D A 1
SD=
SD Card
1SEMICONDUCTORS
