ADC08xx0 Evaluation Module

User's Guide

SLAU715A–February 2017–Revised July 2017

ADC08xx0 Evaluation Module

This user's guide describes the function and use of the ADC08xx0 evaluation module (EVM). Included in

this document are a quick-start guide, instructions for optimizing evaluation results, jumper and connector

descriptions, software description, and alternate hardware configurations.

Contents

1 Overview ...................................................................................................................... 3

1.1 Required Hardware................................................................................................. 3

1.2 Required Software.................................................................................................. 3

1.3 Evaluation Board Feature Identification Summary ............................................................. 4

1.4 References .......................................................................................................... 4

2 Quick-Start Guide............................................................................................................ 5

2.1 Software Installation................................................................................................ 5

2.2 Hardware Setup Procedure ....................................................................................... 6

2.3 Software Setup Procedure......................................................................................... 7

2.4 ADC08100EVM Setup............................................................................................ 10

2.5 Software Setup Procedure ....................................................................................... 10

2.6 ADC08200EVM Setup............................................................................................ 11

2.7 Software Setup Procedure ....................................................................................... 11

2.8 Quick-Start Troubleshooting ..................................................................................... 12

3 Optimizing Evaluation Results............................................................................................ 13

3.1 Clocking Optimization............................................................................................. 13

3.2 Coherent Input Source............................................................................................ 13

3.3 HSDC Pro Settings................................................................................................ 13

4 Alternate Hardware Configurations ...................................................................................... 14

4.1 Clocking Options .................................................................................................. 14

4.2 Delay Pins.......................................................................................................... 14

4.3 Voltage Reference Options ...................................................................................... 14

Appendix A Jumper and Connector Descriptions............................................................................ 15

List of Figures

1 EVM Feature Locations..................................................................................................... 4

2 Quick-Start Test Setup...................................................................................................... 6

3 HSDC Pro GUI Main Panel................................................................................................. 8

4 Data Capture Results for ADC08060 From Quick-Start Procedure................................................... 9

5 Data Capture Results for ADC08100 From Quick-Start Procedure ................................................. 10

6 Data Capture Results for ADC08200 From Quick-Start Procedure ................................................. 11

List of Tables

1 Quick-Start Performance Measurements for ADC08060............................................................... 9

2 Quick-Start Performance Measurements for ADC08100 ............................................................. 10

3 Quick-Start Performance Measurements for ADC08200 ............................................................. 11

4 Troubleshooting Tips ...................................................................................................... 12

5 HSDC Pro Settings to Optimize Results ................................................................................ 13

6 Jumper Descriptions and Default Settings.............................................................................. 15

7 Connector Descriptions.................................................................................................... 15

l TEXAS INSTRUMENTS

www.ti.com

2SLAU715A–February 2017–Revised July 2017

Submit Documentation Feedback

ADC08xx0 Evaluation Module

Trademarks

Microsoft, Windows are registered trademarks of Microsoft Corporation.

All other trademarks are the property of their respective owners.

l TEXAS INSTRUMENTS

www.ti.com

Overview

SLAU715A–February 2017–Revised July 2017

ADC08xx0 Evaluation Module

1 Overview

The ADC08xx0EVM is an evaluation module (EVM) designed to evaluate the ADC08xx0. The EVM

provides simple and minimal external components to minimize system cost and power consumption.

The following features apply to this EVM:

• 8-bit, low-cost, high-speed, CMOS interface ADC08xx0

• External clock for sample clocking with an option to add an onboard crystal oscillator

• Option to provide separate clocks to ADC and FPGA

• TPS7A47 user-programmable RF low-dropout (LDO) voltage regulator

• CDCV304 high-performance, low-skew, PCI_X-compliant clock buffer

• SN74AVC16244 Dynamic Output Control, low-noise 16-bit output buffer

The ADC08xx0EVM is designed to work seamlessly with the TSW1400EVM, TI’s CMOS and LVDS

pattern generator and data-capture board, through the High-Speed Data Converter Pro Graphical User

Interface (HSDC Pro GUI) software tool for high-speed data converter evaluation.

1.1 Required Hardware

The following equipment is included in the EVM evaluation kit:

• ADC08xx0EVM

• Standard banana jack power supply cables

The following list of equipment are items that are not included in the EVM evaluation kit but are items

required for evaluation of this product in order to achieve the best performance:

•TSW1400EVM Data Capture Board, 5-V DC cable connector, and mini-USB cable

• Computer running Microsoft®Windows®8, Windows 7, or Windows XP

• One low-noise signal generator. Recommendations:

– RF generator, > +17 dBm, < –40 dBc harmonics, < 500 fsec jitter 20 kHz–20 MHz, 1-MHz to 2-GHz

frequency range

– Examples: TSW2170EVM, HP HP8644B, Rohde & Schwarz SMA100A

• DC power supply. Recommendations:

– DC Power Supply, 0-6 VDC, > 3 A

– Examples: Agilent E363A or equivalent

• Bandpass filter for desired analog input. Recommendations:

– Filter, ≥60-dB harmonic attenuation, ≤5% bandwidth, > +18-dBm power, < 5-dB insertion loss

– Examples: Trilithic 5VH-series Tunable BPF, K&L BT-series Tunable BPF, TTE KC6 or KC7-series

Fixed BPF

• Signal path cables, SMA or BNC with BNC-to-SMA adapters

1.2 Required Software

The following software is required to operate the TSW1400EVM and is available online. See References,

Section 1.4 for links.

• High-Speed Data Converter Pro software

I TEXAS INSTRUMENTS L/External ADC Clock input Pin Con nectar (CMOS interface) Analog Input +5-V Input Power and GND

Overview

www.ti.com

4SLAU715A–February 2017–Revised July 2017

Submit Documentation Feedback

ADC08xx0 Evaluation Module

1.3 Evaluation Board Feature Identification Summary

The EVM features are labeled in Figure 1.

Figure 1. EVM Feature Locations

1.4 References

• ADC08060 data sheet (SNAS120), available at www.ti.com/product/ADC08060

• ADC08100 data sheet (SNAS060), available at www.ti.com/product/ADC08100

• ADC08200 data sheet (SNAS136), available at www.ti.com/product/ADC08200

• TSW1400EVM User’s Guide (SLWU079), available at www.ti.com/tool/TSW1400EVM

• High-Speed Data Converter Pro software (SLWC107) and User's Guide (SLWU087), available at

www.ti.com/tool/dataconverterpro-sw

NOTE: Schematics, layout, and BOM are available on the ADC08060EVM product page on

www.ti.com.

l TEXAS INSTRUMENTS

www.ti.com

Quick-Start Guide

SLAU715A–February 2017–Revised July 2017

ADC08xx0 Evaluation Module

2 Quick-Start Guide

This section guides the user through the EVM test procedure to obtain a valid data capture from the

ADC08xx0EVM using the TSW1400EVM capture card. This should be the starting point for all evaluations.

2.1 Software Installation

The proper software must be installed before beginning evaluation. See Section 1.2 for a list of the

required software. The References section of this document contains links to find the software on the TI

website.

Important: The software must be installed before connecting the ADC08xx0EVM and TSW1400EVM to

the computer for the first time.

2.1.1 High-Speed Data Converter Pro GUI Installation

The High-Speed Data Converter Pro (HSDC Pro) is used to control the TSW1400EVM and analyze the

captured data. See the HSDC Pro user’s guide (SLWU087) for more information.

1. Download HSDC Pro from the TI website. The References section of this document contains the link to

find the software on the TI website.

2. Extract the files from the zip file.

3. Run setup.exe and follow the installation prompts.

l TEXAS INSTRUMENTS

PC Computer

Running HSDC Pro

ADC08xx0

EVM TSW1400

EVM

Power

Switch

Mini-USB to

USB-A Cable

Analog Input

Low Noise

Signal Generator

10-MHz

Lowpass Filter

Low Noise

Power Supply

+5VDC @3A

10.1 MHz

Vin = -1 dBFS

Clock Source

Quick-Start Guide

www.ti.com

6SLAU715A–February 2017–Revised July 2017

Submit Documentation Feedback

ADC08xx0 Evaluation Module

2.2 Hardware Setup Procedure

A typical test setup using the ADC08xx0EVM and TSW1400EVM is shown in Figure 2. This is the test

setup used for the quick-start procedure. The rest of this section describes the hardware setup steps.

Figure 2. Quick-Start Test Setup

l TEXAS INSTRUMENTS

www.ti.com

Quick-Start Guide

SLAU715A–February 2017–Revised July 2017

ADC08xx0 Evaluation Module

2.2.1 TSW1400EVM Setup

First, set up the TSW1400EVM using the following steps:

1. Connect the ADC08xx0EVM to the TSW1400EVM connecting pin 1 of the CMOS_INTERFACE (J1) to

pin 1 of ADC08xx0EVM output data (J1).

2. Connect the power cable to connector J12 (5 V IN) to the TSW1400EVM.

3. Connect the mini-USB cable to the USB connector (J5).

4. Turn on the power supply. Flip the power switch (SW7) to the ON position. The board should draw

around 0.5 A after power up. This will increase to around 1.7 A when loaded with firmware.

2.2.2 ADC08060EVM Setup

Next, setup the ADC08060EVM using the following:

1. Connect the banana jack power-supply cables to the EVM. Connect the red wire to 5 VDC ±0.1 VDC

of a power supply rated for at least 3 A to connector J4. Connect the black wire to J5 (GND) of the

power supply.

2. Turn on the power supply. The power draw should be around 0.220 A after the clock is supplied.

3. Provide a 60-MHz, –1-dBm clock signal to J3.

4. Set the analog input signal generator for 10.1 MHz, –1 dB from full scale.

5. Place a 10-MHz bandpass filter at the output of the analog signal generator to remove noise and

harmonics from the signal generator.

6. Connect the analog input signal generator to the EVM though SMA connector INPUT (J6) and provide

a 10.1-MHz signal.

2.3 Software Setup Procedure

The software can be opened and configured once the hardware is properly set up.

2.3.1 HSDC Pro GUI Configuration

1. Open High Speed Data Converter Pro by going to Start Menu →All Programs →Texas Instruments →

High Speed Data Converter Pro. The GUI main page looks as shown in Figure 3.

I TEXAS INSTRUMENTS Select Device and Capture Date ._ . ' \ .— . v11 . .... . .. r: : 2 Choose Choose ”10°59 Choose F's-25 5- 2 Test Data Channel Data : l :: DiSP'3V Window .m .. m. m. ..... . .. ,2 a 7" 2'.“ 3 “7° ., m. Check Coherent Freq. AuthalculatiDn Select Size of Data Set Enter Sampling Rate . , ‘ ‘ ‘ _ . . Enter desired input frequency 5°" W" m" m” “n” m” ”a” ' run-unmana- www.mmwu vmhn-mmn ‘ Inn-amu- mumw had-03mm" ; m. awn-mm.

Quick-Start Guide

www.ti.com

8SLAU715A–February 2017–Revised July 2017

Submit Documentation Feedback

ADC08xx0 Evaluation Module

Figure 3. HSDC Pro GUI Main Panel

2. When prompted to select the capture board, select the TSW1400 whose serial number corresponds to

the serial number on the TSW1400EVM and click OK. This popup can be accessed through the

Instrument Options menu.

3. If no firmware is currently loaded, there is a message indicating this. Click on OK.

4. Verify the ADC tab at the top of the GUI is selected.

5. Use the Select ADC drop-down menu at the top left corner to select ADC08060_cmos.

6. When prompted to update the firmware for the ADC, click Yes and wait for the firmware to download to

the TSW1400. This takes a couple of seconds.

7. Enter “60M” into the ADC Output Data Rate field at the bottom left corner then click outside this box or

press Return on the PC keyboard.

8. Click Capture in HSDC Pro to capture data from the ADC.

9. The results from the captured data of Channel 1 should look like Figure 4 and the performance should

be similar to Table 1. If this result is not achieved, then see the Quick Start Troubleshooting section of

this document.

l TEXAS INSTRUMENTS I H2» spa 0.“.an m v4.55 ADEnEnth/wus m um“, , Hdp Tua- Aim \‘E. n‘ 5an mn‘nn mn‘uu chanmw mam] 7mm“ swam j m. umxv A m mm m, r W mu m x mm mm m ‘ m. m an; ‘ m 4044 m x mm 41:53 m r: m Emu“ m ‘ m m“ m ‘ m m m, ‘ immmm éﬁgﬂiﬁiiéria mm. Wm WM @5635 m mama“ in! am .;, m m mg :ww n nuaauanna \vaungu' Kym“ Mm m 7‘ 256m 5mm" zuc‘mu zan‘nn Ann‘nn Asu‘uu j [charm 17 snﬁnn u‘nn m ‘wlvaves AW £21 suc‘mu esn‘nn 70an REW 95527 Hz 4n n7 2n 1:7 2n 1:7 4n 1:7 in ur annr as F: 7n [:7 sour mar ‘ w ‘ ‘ 1 Jenny ﬁnnr ﬁrmware Ver'mm - "o 2" 5 mm a 2 :s ;v pm a‘M ‘ mum m‘m

www.ti.com

Quick-Start Guide

SLAU715A–February 2017–Revised July 2017

ADC08xx0 Evaluation Module

Figure 4. Data Capture Results for ADC08060 From Quick-Start Procedure

Table 1. Quick-Start Performance Measurements for ADC08060

Result Measured Value Units

SNR 46 dBFS

SFDR 62 dBFS

l TEXAS INSTRUMENTS I Madonna-mu." m is m ”.mum gamma.“ vqu m ﬁ mum‘sums E. ‘” one sow wuuo vsuw mm m» M moo mm moo 50m 55m mm 5% wow mum mm . mun-Mu . 80mm v mmm mwm. muzsﬂm u... NV um um ° Q on m m. m ”5.. .m m m, m .34 m. m m. mm son -. a m m. m JILL, w .f‘.w1é:w". m was .; m, «WW... man Q How» DDWW m” n 2» m m m mu m Mu m. w 2014 m 2m m m m 321‘ a... nu ma mu m m. m: ... 5w WWW ymmmmr lsmlwmn-wmur umnxum~cuox_usl_nmr mm mmnrm mmww mm mww ; m tm‘mm

Quick-Start Guide

www.ti.com

10 SLAU715A–February 2017–Revised July 2017

Submit Documentation Feedback

ADC08xx0 Evaluation Module

2.4 ADC08100EVM Setup

Next, setup the ADC08100EVM using the following:

1. Connect the banana jack power-supply cables to the EVM. Connect the red wire to 5 VDC ±0.1 VDC

of a power supply rated for at least 3 A to connector J4. Connect the black wire to J5 (GND) of the

power supply.

2. Turn on the power supply. The power draw should be around 0.220 A after the clock is supplied.

3. Provide a 100-MHz, +5-dBm clock signal to J3.

4. Set the analog input signal generator for 40.1-MHz, –1 dB from full scale.

5. Place a 40-MHz bandpass filter at the output of the analog signal generator to remove noise and

harmonics from the signal generator.

6. Connect the analog input signal generator to the EVM though SMA connector INPUT (J6) and provide

a 40.1-MHz signal.

2.5 Software Setup Procedure

Follow the steps in Section 2.3.1

• When selecting the ADC in the Select ADC drop-down menu, make sure to select ADC08100_cmos

and enter "100M" in ADC Output Data Rate field.

• The results from the captured data of Channel 1 should look like Figure 5 and the performance should

be similar to Table 2. If this result is not achieved, then see the Quick Start Troubleshooting section of

this document.

Figure 5. Data Capture Results for ADC08100 From Quick-Start Procedure

Table 2. Quick-Start Performance Measurements for ADC08100

Result Measured Value Units

SNR 46 dBFS

SFDR 59 dBFS

l TEXAS Imeumum-musn yj, ‘T'ﬁ m hmmom; mumawm magnum MD was HE ADC ii In: INSTRUMENTS Q L). mcnmumm #55 A” “m 5 ‘ ‘ ‘ ‘ ‘ ‘ ‘ ‘ ‘ ‘ ‘ ‘ '31 "mm m «man we 2mm mm man: man man A5Dnn Snuan 5am mun 55cm 7am“: “mum awn—r : cmm Z Bum/wan m \cnnnnem “Hymn: mums“: W mm W .m M NW 5'?" :5: '3? ““' a w u m M m «an m, m m ”M.“ no N nu...“ ma «mm. mm.” 5an m N, g m .2 lvmmasu‘ 1w ‘ 3:??le an a, .ZSL'ZIZSTZE- '9" D' 55535 v 4““ man man .1 Manama ‘2“ ” m n w mu mm mm 2m 3m 2m mu M 5m 55M mu m MN m an» m gun mum thuu-Incvmu hmrwmnun 2 15mm. amm- mum Imu‘aze'we «mysajsxn ms 1w 1 mwv & 1m: lmmzms F H: magma w.

www.ti.com

Quick-Start Guide

SLAU715A–February 2017–Revised July 2017

ADC08xx0 Evaluation Module

2.6 ADC08200EVM Setup

Next, setup the ADC08200EVM using the following:

1. Connect the banana jack power-supply cables to the EVM. Connect the red wire to 5 VDC ±0.1 VDC

of a power supply rated for at least 3 A to connector J4. Connect the black wire to J5 (GND) of the

power supply.

2. Turn on the power supply. The power draw should be around about 0.360 A after the clock is supplied.

3. Provide a 200-MHz, +12-dBm clock signal to J3.

4. Set the analog input signal generator for 55.1 MHz, –1 dB from full scale.

5. Place a 55-MHz bandpass filter at the output of the analog signal generator to remove noise and

harmonics from the signal generator.

6. Connect the analog input signal generator to the EVM though SMA connector INPUT (J6) and provide

a 55.1-MHz signal.

2.7 Software Setup Procedure

Follow the steps in Section 2.3.1

• When selecting the ADC in the Select ADC drop-down menu, make sure to select ADC08200_cmos

and enter "200M" in ADC Output Data Rate field.

• The results from the captured data of Channel 1 should look like Figure 6 and the performance should

be similar to Table 3. If this result is not achieved, then see the Quick Start Troubleshooting section of

this document.

Figure 6. Data Capture Results for ADC08200 From Quick-Start Procedure

Table 3. Quick-Start Performance Measurements for ADC08200

Result Measured Value Units

SNR 44 dBFS

SFDR 53 dBFS

l TEXAS INSTRUMENTS

Quick-Start Guide

www.ti.com

12 SLAU715A–February 2017–Revised July 2017

Submit Documentation Feedback

ADC08xx0 Evaluation Module

2.8 Quick-Start Troubleshooting

Use Table 4 to assist with problems that may have occurred during the quick-start procedure.

Table 4. Troubleshooting Tips

Issue Troubleshooting Tips

General problems Verify the test setup shown in Section 2 and repeat the setup procedure as described in

this document.

Check power supplies to the EVMs. Verify that the power switches are in the ON position

and supplies are drawing the appropriate current.

Check signal and clock connections to the EVM.

Check that all boards are properly connected together.

Try power-cycling the external power supply to the EVM and reprogram the ADC devices.

TSW1400 LEDs are not correct:

D2 – D9 OFF Verify the settings of the configuration switches on the TSW1400EVM.

Verify that the EVM configuration GUI is communicating with the USB and that the

configuration procedure has been followed.

Try capturing data in HSDC Pro to force an LED status update.

HSDC Pro software is not

capturing good data or analysis

results are incorrect.

Verify that the TSW1400EVM is properly connected to the PC with a mini-USB cable and

that the board serial number is properly identified by the HSDC Pro software.

Check that the proper ADC device is selected.

Check that the analysis parameters are properly configured.

Check that the fundamental power is no larger than –1 dBFs.

Verify that the clock amplitude is correct for the particular device being used. If the issue

persists, then increase the clock amplitude

HSDC Pro software gives a time-

out error when capturing data Restart HSDC Pro and reload the firmware.

Verify that the ADC sampling rate is correct in the HSDC Pro software.

Sub-optimal measured

performance Measure test points to verify operating voltage ranges.

Verify the jumper configurations are in default locations.

Verify that filters are used in the clock and input signal paths and that low-noise signal

sources are used.

l TEXAS INSTRUMENTS

www.ti.com

Optimizing Evaluation Results

SLAU715A–February 2017–Revised July 2017

ADC08xx0 Evaluation Module

3 Optimizing Evaluation Results

This section assists the user in optimizing the performance during evaluation of the product.

3.1 Clocking Optimization

The sampling clock provided to the ADC needs to have very low phase noise to achieve optimal results.

The default EVM configuration uses a crystal oscillator to generate the sampling clock. Another option to

improve the clock noise performance is bypassing the onboard clock in favor of an external clock. The

clock must have very low noise and must use an external narrow pass-band filter to achieve optimal noise

performance. The clock amplitude must be within the data sheet limits. See Section 4 for more information

regarding this setup.

3.2 Coherent Input Source

ARectangular window function can be applied to the captured data when the sample rate and the input

frequency are set precisely to capture an integer number of cycles of the input frequency (sometimes

called coherent frequency). This may yield better SNR results. The clock and analog inputs must be

frequency locked (such as through 10-MHz references) in order to achieve coherency.

3.3 HSDC Pro Settings

HSDC Pro has some settings that can help improve the performance measurements. These are

highlighted in Table 5.

Table 5. HSDC Pro Settings to Optimize Results

HSDC Pro Feature Description

Analysis Window (Samples) Selects the number of samples to include in the selected test analysis. Collect more data to

improve frequency resolution of Fast-Fourier Transform (FFT) analysis. If more than 65,536

samples are required, increase the setting in the Data Capture Options to match this value.

Data Windowing Function Select the desired windowing function applied to the data for FFT analysis. Select Blackman when

sampling a non-coherent input signal or Rectangle when sampling a coherent input signal.

Test Options →Notch

Frequency Bins Select bins to be removed from the spectrum and back-filled with the average noise level. May

also customize which Harmonics and Spurs are considered in SNR and THD calculations and

select the method for calculating spur power.

Test Options →Bandwidth

Integration Markers Enable markers to narrow the Single-Tone FFT test analysis to a specific bandwidth.

Data Capture Options →

Capture Options Configure the number of contiguous samples per capture (capture depth). May also enable

Continuous Capture and FFT Averaging.

l TEXAS INSTRUMENTS

Alternate Hardware Configurations

www.ti.com

14 SLAU715A–February 2017–Revised July 2017

Submit Documentation Feedback

ADC08xx0 Evaluation Module

4 Alternate Hardware Configurations

This section describes alternate hardware configurations in order to achieve better results or to more

closely mimic the system configuration.

4.1 Clocking Options

The default clocking mode uses an external clock to generate the ADC sampling clock and FPGA clocks.

An alternative option is described in the following section.

4.1.1 Onboard Oscillator Clock

An option to provide a clock source through an onboard oscillator is available. The pad on Y1 can be filled

with a 6-pin SMD, no lead (7.00 mm x 5.00 mm) oscillator to provide the sampling clock for the ADC. For

this option, SHUNT (JP7) to provide power to the VDD pin of the oscillator and bypass the external clock

by changing the position of jumper (JP2) to SHUNT 1–2.

4.1.2 Separating the ADC and FPGA Clock

A separate clock can be provided to both the ADC and FPGA by removing R18 and adding R14. Also,

SHUNT (JP10) to position 1-2 to provide power to the Clock Buffer. Now, J7 can be used to provide the

clock signal for the FPGA, while J3 can be used to provide the clock to the ADC.

4.2 Delay Pins

Pins J8–J11 can be used to add a delay to the clock signal going into the FPGA. By default, pins J8 and

J12 are SHUNT but the jumper can be positioned with any of the other J8–J11 pins. The default position

of J8 and J12 adds about 0.5 ns to 1.7 ns of delay; the delay increases as the jumper is positioned with

the other pins. In other words, the delay is 2× as much or 1.0 ns to 3.4 ns when J9 and J12 are SHUNT,

3× or 1.5 ns to 5.1 ns when J10 and J12 are SHUNT, and 4× or 2.0 ns to 6.8 ns when J11 and J12 are

SHUNT.

4.3 Voltage Reference Options

The default configurations uses a LM8272 rail-to-rail precision op amp to drive the reference voltage. By

default, the top reference voltage is set to 1.9 V and the bottom voltage is set to 0.3 V. Alternative options

are described in the follow sections.

4.3.1 External Voltage Reference

An external voltage reference can be used to supply the reference voltage to the ADC. For this option,

jumper VRT (JP9) and VRB (JP8) must be pulled out and left OPEN. Apply a top voltage reference at the

test point VRTP (TP5) and bottom reference at VRBP (TP6). If the desired voltage references are 3 V and

GND, change jumpers JP9 and JP8 to SHUNT 2-3.

4.3.2 Divider Resistor Modification

If the LM8272 is desired to drive the reference voltages, but at a different range, the divider resistors (R1

and R3) can be changed to suit the reference voltage needed. R1 and R3 are larger for easy soldering

modifications.

l TEXAS INSTRUMENTS

SLAU715A–February 2017–Revised July 2017

Jumper and Connector Descriptions

Appendix A

SLAU715A–February 2017–Revised July 2017

Jumper and Connector Descriptions

A.1 Jumper Descriptions

The EVM jumpers are shown in Table 6 as well as the default settings for the jumpers. Use this table to

reset the EVM in the default configuration, in case of issues.

Table 6. Jumper Descriptions and Default Settings

Jumper Description Default Setting

JP2 Selects either onboard or external sample clock Shunt pins 2-3

JP3 Option to bypass clock buffer OPEN

JP4 Enable outputs from clock buffer (active high) Shunt pins 1-2

JP5 Option to bypass clock buffer Shunt pins 2-3

JP6 Powerdown mode for ADC08xx0 (default not in powerdown mode) Shunt pins 2-3

JP7 Provides power to onboard clock OPEN

JP8 Top reference voltage option (supplied by LM8272 by default) Shunt pins 1-2

JP9 Bottom reference voltage option (supplied by LM8272 by default) Shunt pins 1-2

JP10 Enable outputs from second clock buffer (active low) Shunt pins 2-3

J8-J12 Option for adding delay to output clock signal Shunt pins J8-J12

A.2 Connector Descriptions

The EVM connectors and their function are described in Table 7.

Table 7. Connector Descriptions

Connector Description

J1 CMOS pin header connector

J2 Clock output for ADC sampling and FPGA

J3 External ADC sample clock input

J4 5-V DC banana jack connector

J5 GND banana jack connector

J6 Single-ended SMA analog input

J7 Second clock output for ADC sampling and FPGA (Optional)

Revision History

NOTE: Page numbers for previous revisions may differ from page numbers in the current version.

Changes from Original (February 2017) to A Revision .................................................................................................. Page

• Added support for the ADC08100EVM and ADC08200EVM to the user's guide globally....................................... 1

STANDARD TERMS FOR EVALUATION MODULES

1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or

documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance

with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.

1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility

evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not

finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For

clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions

set forth herein but rather shall be subject to the applicable terms that accompany such Software

1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,

or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production

system.

2Limited Warranty and Related Remedies/Disclaimers:

2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License

Agreement.

2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM

to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by

neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have

been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications

or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control

techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.

User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)

business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.

2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit

User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty

period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or

replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be

warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day

warranty period.

3Regulatory Notices:

3.1 United States

3.1.1 Notice applicable to EVMs not FCC-Approved:

FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software

associated with the kit to determine whether to incorporate such items in a finished product and software developers to write

software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or

otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition

that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.

Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must

operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.

3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:

CAUTION

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to

operate the equipment.

FCC Interference Statement for Class A EVM devices

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

FCC Interference Statement for Class B EVM devices

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

3.2 Canada

3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247

Concerning EVMs Including Radio Transmitters:

This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:

(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may

cause undesired operation of the device.

Concernant les EVMs avec appareils radio:

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation

est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit

accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Concerning EVMs Including Detachable Antennas:

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)

gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type

and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for

successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types

listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.

Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited

for use with this device.

Concernant les EVMs avec antennes détachables

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et

d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage

radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope

rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le

présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le

manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne

non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de

l'émetteur

3.3 Japan

3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に

輸入される評価用キット、ボードについては、次のところをご覧ください。

http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page

3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified

by TI as conforming to Technical Regulations of Radio Law of Japan.

If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the

instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs

(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):

1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal

Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for

Enforcement of Radio Law of Japan,

2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to

EVMs, or

3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan

with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note

that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.

【無線電波を送信する製品の開発キットをお使いになる際の注意事項】開発キットの中には技術基準適合証明を受けて

いないものがあります。技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの

措置を取っていただく必要がありますのでご注意ください。

1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用

いただく。

2. 実験局の免許を取得後ご使用いただく。

3. 技術基準適合証明を取得後ご使用いただく。

なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。

上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。日本テキサス・イ

ンスツルメンツ株式会社

東京都新宿区西新宿６丁目２４番１号

西新宿三井ビル

3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page

電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/

/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page

3.4 European Union

3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):

This is a class A product intended for use in environments other than domestic environments that are connected to a

low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this

product may cause radio interference in which case the user may be required to take adequate measures.

4EVM Use Restrictions and Warnings:

4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT

LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.

4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling

or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information

related to, for example, temperatures and voltages.

4.3 Safety-Related Warnings and Restrictions:

4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user

guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and

customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input

and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or

property damage. If there are questions concerning performance ratings and specifications, User should contact a TI

field representative prior to connecting interface electronics including input power and intended loads. Any loads applied

outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible

permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any

load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.

During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit

components may have elevated case temperatures. These components include but are not limited to linear regulators,

switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the

information in the associated documentation. When working with the EVM, please be aware that the EVM may become

very warm.

4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the

dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.

User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,

affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic

and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely

limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and

liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or

designees.

4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,

state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all

responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and

liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local

requirements.

5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate

as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as

accurate, complete, reliable, current, or error-free.

6. Disclaimers:

6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT

LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL

FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT

NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE

SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.

6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE

CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR

INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE

EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR

IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.

7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS

LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,

EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY

HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY

WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL

THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.

8. Limitations on Damages and Liability:

8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,

INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE

TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR

REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,

OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF

USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI

MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS

OCCURRED.

8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED

HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN

CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR

EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE

CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.

9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)

will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in

a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable

order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),

excluding any postage or packaging costs.

10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,

without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to

these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.

Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief

in any United States or foreign court.

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

IMPORTANT NOTICE FOR TI DESIGN INFORMATION AND RESOURCES

Texas Instruments Incorporated (‘TI”) technical, application or other design advice, services or information, including, but not limited to,

reference designs and materials relating to evaluation modules, (collectively, “TI Resources”) are intended to assist designers who are

developing applications that incorporate TI products; by downloading, accessing or using any particular TI Resource in any way, you

(individually or, if you are acting on behalf of a company, your company) agree to use it solely for this purpose and subject to the terms of

this Notice.

TI’s provision of TI Resources does not expand or otherwise alter TI’s applicable published warranties or warranty disclaimers for TI

products, and no additional obligations or liabilities arise from TI providing such TI Resources. TI reserves the right to make corrections,

enhancements, improvements and other changes to its TI Resources.

You understand and agree that you remain responsible for using your independent analysis, evaluation and judgment in designing your

applications and that you have full and exclusive responsibility to assure the safety of your applications and compliance of your applications

(and of all TI products used in or for your applications) with all applicable regulations, laws and other applicable requirements. You

represent that, with respect to your applications, you have all the necessary expertise to create and implement safeguards that (1)

anticipate dangerous consequences of failures, (2) monitor failures and their consequences, and (3) lessen the likelihood of failures that

might cause harm and take appropriate actions. You agree that prior to using or distributing any applications that include TI products, you

will thoroughly test such applications and the functionality of such TI products as used in such applications. TI has not conducted any

testing other than that specifically described in the published documentation for a particular TI Resource.

You are authorized to use, copy and modify any individual TI Resource only in connection with the development of applications that include

the TI product(s) identified in such TI Resource. NO OTHER LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE TO

ANY OTHER TI INTELLECTUAL PROPERTY RIGHT, AND NO LICENSE TO ANY TECHNOLOGY OR INTELLECTUAL PROPERTY

RIGHT OF TI OR ANY THIRD PARTY IS GRANTED HEREIN, including but not limited to any patent right, copyright, mask work right, or

other intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information

regarding or referencing third-party products or services does not constitute a license to use such products or services, or a warranty or

endorsement thereof. Use of TI Resources may require a license from a third party under the patents or other intellectual property of the

third party, or a license from TI under the patents or other intellectual property of TI.

TI RESOURCES ARE PROVIDED “AS IS” AND WITH ALL FAULTS. TI DISCLAIMS ALL OTHER WARRANTIES OR

REPRESENTATIONS, EXPRESS OR IMPLIED, REGARDING TI RESOURCES OR USE THEREOF, INCLUDING BUT NOT LIMITED TO

ACCURACY OR COMPLETENESS, TITLE, ANY EPIDEMIC FAILURE WARRANTY AND ANY IMPLIED WARRANTIES OF

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF ANY THIRD PARTY INTELLECTUAL

PROPERTY RIGHTS.

TI SHALL NOT BE LIABLE FOR AND SHALL NOT DEFEND OR INDEMNIFY YOU AGAINST ANY CLAIM, INCLUDING BUT NOT

LIMITED TO ANY INFRINGEMENT CLAIM THAT RELATES TO OR IS BASED ON ANY COMBINATION OF PRODUCTS EVEN IF

DESCRIBED IN TI RESOURCES OR OTHERWISE. IN NO EVENT SHALL TI BE LIABLE FOR ANY ACTUAL, DIRECT, SPECIAL,

COLLATERAL, INDIRECT, PUNITIVE, INCIDENTAL, CONSEQUENTIAL OR EXEMPLARY DAMAGES IN CONNECTION WITH OR

ARISING OUT OF TI RESOURCES OR USE THEREOF, AND REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

You agree to fully indemnify TI and its representatives against any damages, costs, losses, and/or liabilities arising out of your non-

compliance with the terms and provisions of this Notice.

This Notice applies to TI Resources. Additional terms apply to the use and purchase of certain types of materials, TI products and services.

These include; without limitation, TI’s standard terms for semiconductor products http://www.ti.com/sc/docs/stdterms.htm), evaluation

modules, and samples (http://www.ti.com/sc/docs/sampterms.htm).

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

ADC08xx0EVM User Guide Datasheet by Texas Instruments

INFORMATION

HELP

CONTACT US

FOLLOW US
